SpectraPor® 1-4 Dry Standard RC Single-layer Dialysis Membrane

SpectraPor® 1-4 Single-Layer RC membranes are available as pre-cut discs or large square sheets that can be cut-to-size for use in assembled flat-sheet dialysis systems (equilibrium dialyzer, microdialyzer and macrodialyzer) to study molecular affinity, enzyme activity and biochemical interactions.  Provided dry with or without glycerin, Standard Grade RC is a clear and flexible membrane that does not carry a fixed charge, exhibits low adsorption and contains trace heavy metals and sulfur compounds that can easily be removed (refer to User Guide).  Standard Grade RC membrane has a good chemical compatibility with concentrated-weak or diluted-strong acids & bases, most alcohols and some organic solvents, while tolerating pH 2 - 12 and temperature 4 - 121° C. Compatibility to specific solvents should be confirmed on the Chemical Compatibility table.

Custom SpectraPor 1-4 dialysis single-layer membrane

Consider custom-cut and packaged 1-ply membrane discs, sheets or strips; ready for easy assembly in dialysis devices and apparatus, or for OEM assay kits.

FEATURES AND BENEFITS
Low cost and economical membrane3 standard diameter disc sizes for commercial dialysis systems
Good chemical compatibility and operating conditions toleranceCustomization available for high volume use or OEM
Dry sheets for easy cutting and use with adhesives
Product specifications

SpectraPor® 1-3 Standard RC Single-layer Membrane

Membrane Type Purpose MWCO Glycerin Configurations
SpectraPor® 1 Basic Dialysis 6-8 kD Yes Discs and Sheets
SpectraPor® 2 Higher permeability 12-14 kD Yes Discs and Sheets
SpectraPor® 3 Basic Dialysis 3.5 kD No Discs and Sheets
Membrane Configuration Dics Square Sheets
Properties: Hydrophilic, symmetric porosity Hydrophilic, symmetric porosity
Size: 33 mm, 47 mm and 100 mm dia. (refer to part number table)
Packaging: Dry with or without glycerin Dry with or without glycerin
Quantity: 50 discs/pkg 25 sheets/pkg

Part Numbers and specifications



View All MWCO
(kD)
Disc Diameter
(mm)
Qty. Part No.
SpectraPor®1


6-8

33

47

50

132478

132476

SpectraPor®2


12-14



33

47



50

132482

132480

SpectraPor®3


3.4



33

47



50

132488

132486

  MWCO
(kD)
Size
(mm)
Qty. Part No.
Spectra/Por 1


6-8

240 x 240

25

132677

Spectra/Por 2


12-14

200 x 200

25

132686

Spectra/Por 3


3.4

108 x 108

25

132723
